- Size: 8.5
- Place of Origin: shandong
- Brand Name: QINGONG
- Model Number: CPQD35FR
- Weight: 3500.000 kg
1 | Model | CPQYD30FR | CPQYD35FR | |||
2 | Rated capacity | kg | 3000 | 3500 | ||
3 | Load center | mm | 500 | 500 | ||
4 | Power type | Gasoline/LPG | Gasoline/LPG | |||
5 | Transmission | Hydraulic | Hydraulic | |||
Dimensions | 6 | Lifting height | mm | 3000 | 3000 | |
7 | Free lifting height | mm | 80 | 80 | ||
8 | Turning radius | mm | 2500 | 2500 | ||
9 | Overall length | mm | 3800 | 3800 | ||
10 | Overall width | mm | 1230 | 1230 | ||
11 | Overall height (mast lowered) | mm | 2110 | 2110 | ||
12 | Overall height (mast raised) | mm | 4270 | 4270 | ||
13 | Overall height (overhead guard) | mm | 2110 | 2110 | ||
14 | Fork length | mm | 1220 | 1220 | ||
15 | Fork width | mm | 125 | 125 | ||
16 | Fork thickness | mm | 45 | 50 | ||
Performance | 17 | Max. driving speed (with/without load) | km/h | 18/20 | 18/20 | |
18 | Max. lifting speed (with load) | mm/s | 400 | 375 | ||
19 | Max. traction (with/without load) | kn | 15.5/10.5 | 16/11 | ||
20 | Gradeability (with/without load) | % | 15/20 | 15/20 | ||
21 | Tilting angles(forward/backward) | ° | 6/12 | 6/12 | ||
22 | Service weight | kg | 4320 | 4580 | ||
Engine | 23 | Engine model | BY491GP | BY491GP | ||
24 | Power | kw | 41 | 41 | ||
25 | Rated speed | rpm | 2800 | 2800 | ||
26 | Displacement | L | 2.237 | 2.237 | ||
27 | No. of cylinder | 4 | 4 | |||
Wheel | 28 | Front overhang | mm | 465 | 465 | |
29 | Wheel base | mm | 1700 | 1750 | ||
30 | Front tread | mm | 1000 | 1000 | ||
31 | Rear tread | mm | 970 | 970 | ||
32 | Front tire | 28*9-15 | 28*9-15 | |||
33 | Rear tire | 6.50-10 | 6.50-10 | |||
