- Size: 8.5
- Place of Origin: shandong
- Brand Name: QINGONG
- Model Number: CPQD25FR
- Weight: 2500.000 kg
1 | Model | CPQYD20FR | CPQYD25FR | ||
2 | Rated capacity | kg | 2000 | 2500 | |
3 | Load center | mm | 500 | 500 | |
4 | Power type | Gasoline/LPG | Gasoline/LPG | ||
5 | Transmission | Hydraulic | Hydraulic | ||
Dimensions | 6 | Lifting height | mm | 3000 | 3000 |
7 | Free lifting height | mm | 60 | 60 | |
8 | Turning radius | mm | 2450 | 2450 | |
9 | Overall length | mm | 3605 | 3605 | |
10 | Overall width | mm | 1160 | 1160 | |
11 | Overall height (mast lowered) | mm | 2095 | 2095 | |
12 | Overall height (mast raised) | mm | 4080 | 4080 | |
13 | Overall height (overhead guard) | mm | 2095 | 2095 | |
14 | Fork length | mm | 1070 | 1070 | |
15 | Fork width | mm | 100 | 122 | |
16 | Fork thickness | mm | 40 | 40 | |
Performance | 17 | Max. driving speed (with/without load) | km/h | 17/19 | 17/19 |
18 | Max. lifting speed (with load) | mm/s | 400 | 400 | |
19 | Max. traction (with/without load) | kn | 14/9 | 15/10 | |
20 | Gradeability (with/without load) | % | 15/20 | 15/20 | |
21 | Tilting angles(forward/backward) | ° | 6/12 | 6/12 | |
22 | Service weight | kg | 3320 | 3600 | |
Engine | 23 | Engine model | BY491GP | BY491GP | |
24 | Power | kw | 41 | 41 | |
25 | Rated speed | rpm | 2800 | 2800 | |
26 | Displacement | L | 2.237 | 2.237 | |
27 | No. of cylinder | 4 | 4 | ||
Wheel | 28 | Front overhang | mm | 451 | 451 |
29 | Wheel base | mm | 1640 | 1640 | |
30 | Front tread | mm | 970 | 970 | |
31 | Rear tread | mm | 970 | 970 | |
32 | Front tire | 7.00-12 | 7.00-12 | ||
33 | Rear tire | 6.00-9 | 6.00-9 |
