- Size: 6
- Place of Origin: shandong
- Brand Name: QINGONG
- Model Number: CPD30C
- Weight: 3000.000 kg
1 | Model | CPD30J | CPD35J | ||
2 | Rated capacity | kg | 3000 | 3500 | |
3 | Load center | mm | 500 | 500 | |
4 | Power type | Battery | Battery | ||
Dimensions | 5 | Lifting height | mm | 3000 | 3000 |
6 | Free lifting height | mm | 110 | 110 | |
7 | Turning radius | mm | 2400 | 2500 | |
8 | Overall length | mm | 4000 | 4040 | |
9 | Overall width | mm | 1240 | 1240 | |
10 | Overall height (mast lowered) | mm | 2200 | 2200 | |
11 | Overall height (mast raised) | mm | 4260 | 4260 | |
12 | Overall height (overhead guard) | mm | 2230 | 2300 | |
13 | Fork length | mm | 1220 | 1220 | |
14 | Fork width | mm | 125 | 125 | |
15 | Fork thickness | mm | 45 | 45 | |
Performance | 16 | Max. driving speed (with/without load) | km/h | 13/14 | 12.4/13.8 |
17 | Max. lifting speed (with load) | mm/s | 260 | 275 | |
18 | Max. traction (with load) | kn | 15 | 17 | |
19 | Gradeability (with load) | % | 12 | 12 | |
20 | Tilting angles (forward/backward) | ° | 6/12 | 6/12 | |
21 | Service weight | kg | 4940 | 5160 | |
Motor | 22 | Traction motor | JXQ-16.6 | JXQ-16.6 | |
23 | Lifting motor | XQD-13-3S | XQD-13-3S | ||
Battery | 24 | Battery type | 40-DA-500 | 40-DA-500 | |
25 | Battery voltage/capacity | V/Ah | 80/500 | 80/500 | |
Wheel | 26 | Front overhang | mm | 465 | 465 |
27 | Wheel base | mm | 1685 | 1685 | |
28 | Front tread | mm | 1010 | 1010 | |
29 | Rear tread | mm | 975 | 975 | |
30 | Front tire | 28*9-15 | 28*9-15 | ||
31 | Rear tire | 5.00-8 | 5.00-8 |
- Size: 6
- Place of Origin: shandong
- Brand Name: QINGONG
- Model Number: CPD30C
- Weight: 3000.000 kg
1 | Model | CPD30J | CPD35J | ||
2 | Rated capacity | kg | 3000 | 3500 | |
3 | Load center | mm | 500 | 500 | |
4 | Power type | Battery | Battery | ||
Dimensions | 5 | Lifting height | mm | 3000 | 3000 |
6 | Free lifting height | mm | 110 | 110 | |
7 | Turning radius | mm | 2400 | 2500 | |
8 | Overall length | mm | 4000 | 4040 | |
9 | Overall width | mm | 1240 | 1240 | |
10 | Overall height (mast lowered) | mm | 2200 | 2200 | |
11 | Overall height (mast raised) | mm | 4260 | 4260 | |
12 | Overall height (overhead guard) | mm | 2230 | 2300 | |
13 | Fork length | mm | 1220 | 1220 | |
14 | Fork width | mm | 125 | 125 | |
15 | Fork thickness | mm | 45 | 45 | |
Performance | 16 | Max. driving speed (with/without load) | km/h | 13/14 | 12.4/13.8 |
17 | Max. lifting speed (with load) | mm/s | 260 | 275 | |
18 | Max. traction (with load) | kn | 15 | 17 | |
19 | Gradeability (with load) | % | 12 | 12 | |
20 | Tilting angles (forward/backward) | ° | 6/12 | 6/12 | |
21 | Service weight | kg | 4940 | 5160 | |
Motor | 22 | Traction motor | JXQ-16.6 | JXQ-16.6 | |
23 | Lifting motor | XQD-13-3S | XQD-13-3S | ||
Battery | 24 | Battery type | 40-DA-500 | 40-DA-500 | |
25 | Battery voltage/capacity | V/Ah | 80/500 | 80/500 | |
Wheel | 26 | Front overhang | mm | 465 | 465 |
27 | Wheel base | mm | 1685 | 1685 | |
28 | Front tread | mm | 1010 | 1010 | |
29 | Rear tread | mm | 975 | 975 | |
30 | Front tire | 28*9-15 | 28*9-15 | ||
31 | Rear tire | 5.00-8 | 5.00-8 |
